FAA Information Effective: 3/7/2013
AOPA members save at 3,000+ GA airports.Book Now!
KARBCivil
Public Use
Public Use
Ann Arbor Municipal
Ann Arbor, MI
Phone: 734-994-9124
Nearby airports
Operations | Communications | Weather |
Runways |
Comments |
Remarks |
Procedures | Services, Businesses & FBOsKneeboard Format
Overview
| Attendance: |
Attended Terminal Open 0700-Dusk.Nov-Mar, 7 Days a Week,0800-2000Apr-Oct, 7 Days a Week,0800-1800 |
| Tower: | Air Traffic Control Tower, 12 hrs/day, everyday, year-round |
| Elevation: | 839 ft (255.7 m) (Estimated) |
| Location: | 3.00 mi. S of Ann Arbor |
| Beacon: | Present (white-green) |
| Approaches: | VOR, RNAV, GPS |
| Runways: | 06/24, 12/30
(unpaved)
Longest paved runway: 3505 ft |
| Fees: | Parking, Tiedown, Hangar |
Expand Additional Remarks
Runway 06/24
| Dimensions: | 3505 x 75ft. / 1068.3 x 22.9m | Weight Bearing Cap: | Single wheel: 45000 lb |
| Surface: | concrete, grooved, in fair condition | Runway Edge Lights: | medium |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 06 | 831.3ft. MSL 60° mag 55° true 0.2% down |  | non-precision | runway end identifier: REIL is present visual glide slope: 4-Light/Left-Side PAPI | Trees, 370 ft Left of center, 33 ft high, 924 ft from end, 21:1 clearance slope | Ry 06, PAPI Unusable 7 Degs Left & Right of Course | ||||
| 24 | 826.0ft. MSL 240° mag 235° true 0.2% up | | non-precision | approach: Omni-directional ALS visual glide slope: 2-Box/Left-Side VASI | Trees, Both-Sides, 59 ft high, 1,500 ft from end, 22:1 clearance slope | |||||
Runway 12/30
| Dimensions: | 2750 x 110ft. / 838.2 x 33.5m | Weight Bearing Cap: | |
| Surface: | turf, grass, sod, no surface treatment, in fair condition | Runway Edge Lights: |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 12 | 839.0ft. MSL 127° mag 122° true 0.6% down | | No Data | Trees, Both-Sides, 42 ft high, 990 ft from end, 23:1 clearance slope | 12/30 Mkd with Yellow Cones | |||||
| 30 | 822.0ft. MSL 307° mag 302° true 0.6% up | | No Data | Trees, 115 ft Left of center, 60 ft high, 768 ft from end, 12:1 clearance slope | ||||||
Business/Service Information
| Name | Location | Freq. Monitored | Main Phone | |
|---|---|---|---|---|
| Ann Arbor Flyers |
| On field: CTR | ||
| Aviation Center, Inc. |
| On field: NE |
UNICOM: 123.0 | 734-662-6806 |
| Bijan Air, Inc. |
| On field: N |
UNICOM: 122.85 | 734-769-9699 |
| Michigan Flyers |
| On field: NW | 734-994-6208 | |
| Solo Aviation, Inc. |
| On field: Ctr |
UNICOM: 123.0 | 734-994-6651 |
Expand Nearby restaurants, attractions
Operations & More Information
| Lat/Long: | N42 13.3790' / W83 44.7364' |
| Charts: | NACO:
Detroit Sectional |
| Mag Var: | 05W (1985) |
| ARTCC: | Cleveland (ZOB) |
| FSS: | Lansing (LAN) 1-800-WXBRIEF |
| NOTAM Facility: | ARB |
| Approach/Departure Control Facility | DTW |
| Pattern Altitude: | Fixed Wing: 1839 MSL |
| Wind Indicator: | Lighted |
| Seg. Circle: | Yes |
| Lighting: | When ATCT Clsd Actvt ODALS Ry 24 - CTAF |
Aircraft & Activity
Based GA Aircraft
| Single Engine: | 141 |
| Multi Engine: | 15 |
| Jets: | 1 |
| Helicopters: | 10 |
| Gliders: | |
| Ultralights: | 1 |
Airport Activity
| GA Local: | 37,511 |
| GA Itinerant: | 21,174 |
| Commercial: | |
| Air Taxi: | 0 |
| Military: |
(12-month period ending on 12/31/2011)
Air Safety Institute Resources
Expand Communications Card
Contact Addresses
| ASN Volunteer: | Owner: | Airport Manager: |
| Mark Perry | Roger W. Fraser | Matthew Kulhanek |
| 100 N, Fifth Ave | 100 N, Fifth Ave, P.O. Box 8647 | |
| Ann Arbor, MI 48104 | Ann Arbor, MI 48107-8647 | |
| 734-994-2650 (Office) | 734-994-9124 (Office) | |
| Contact the ASN Volunteer | ||
| Airport Manager Admin |
