FAA Information Effective: 3/7/2013
AOPA members save at 3,000+ GA airports.Book Now!
KOFKCivil
Public Use
Public Use
Norfolk Regional/Karl Stefan Memorial Field
Norfolk, NE
Phone: 402-841-5130
www.norfolkairportservices.net
Nearby airports
Operations | Communications | Weather |
Runways |
Comments |
Remarks |
Procedures | Services, Businesses & FBOsKneeboard Format
Overview
| Attendance: |
Attended For Service After Hrs Call 402-841-5130.Year-round, 7 Days a Week,Daylight |
| Tower: | No |
| Elevation: | 1,572 ft (479.1 m) (Surveyed) |
| Location: | 3.00 mi. SW of Norfolk |
| Beacon: | Present (white-green) |
| Approaches: | ILS, LOC, VOR, RNAV, GPS |
| Runways: | 01/19, 14/32
Longest paved runway: 5800 ft |
| Fees: | Hangar |
Expand Additional Remarks
Runway 01/19
| Dimensions: | 5800 x 100ft. / 1767.8 x 30.5m | Weight Bearing Cap: | Single wheel: 60000 lb |
| Surface: | asphalt, porous friction course, in good condition | Runway Edge Lights: | high |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | 1572.6ft. MSL 14° mag 19° true 0.7% down |  | precision | approach: 1400ft/Medium-Intensity/Runway Alignment Indicators visual glide slope: 4-Light/Left-Side PAPI | ILS | Tree, 425 ft Left of center, 137 ft high, 5,700 ft from end, 40:1 clearance slope | ||||
| 19 | 1530.3ft. MSL 194° mag 199° true 0.7% up | | non-precision | visual glide slope: 4-Light/Left-Side PAPI | Tree, 550 ft Right of center, 50 ft high, 1,400 ft from end, 24:1 clearance slope | |||||
Runway 14/32
| Dimensions: | 5800 x 100ft. / 1767.8 x 30.5m | Weight Bearing Cap: | Single wheel: 75000 lb |
| Surface: | asphalt, porous friction course, in good condition | Runway Edge Lights: | medium |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 14 | 1542.9ft. MSL 137° mag 142° true 0.4% up | | non-precision | visual glide slope: 4-Light/Left-Side PAPI | 284' Disp Threshold | Railroad, 375 ft Right of center, 25 ft high, 990 ft from end, 31:1 clearance slope | ||||
| 32 | 1564.0ft. MSL 317° mag 322° true 0.4% down | | non-precision | runway end identifier: REIL is present visual glide slope: 4-Light/Left-Side PAPI | 357' Disp Threshold | Tree, 400 ft Right of center, 48 ft high, 1,200 ft from end, 20:1 clearance slope | ||||
Business/Service Information
| Name | Location | Freq. Monitored | Main Phone | |
|---|---|---|---|---|
| Norfolk Airport Services |
| On field: NE |
UNICOM: 122.7 | 402-379-7810 |
Services at this airport:
Services:Engine Repair: MajorAirframe Repair: Major
Fuel: 100LL Low-Lead, Jet A
Transportation:
Rental Cars:
| Enterprise | Book Now! | 866-315-9155 |
Expand Nearby restaurants, attractions
Operations & More Information
| Lat/Long: | N41 59.1283' / W97 26.1067' |
| Charts: | NACO:
Omaha Sectional |
| Mag Var: | 05E (2005) |
| ARTCC: | Minneapolis (ZMP) |
| FSS: | Columbus (OLU) 1-800-WXBRIEF |
| NOTAM Facility: | OFK |
| Approach/Departure Control Facility | |
| Pattern Altitude: | Fixed Wing: 2572 MSL |
| Wind Indicator: | Lighted |
| Seg. Circle: | Yes |
| Lighting: | Pilot Activated Lighting:
|
Aircraft & Activity
Based GA Aircraft
| Single Engine: | 39 |
| Multi Engine: | 3 |
| Jets: | 1 |
| Helicopters: | 0 |
| Gliders: | |
| Ultralights: | 5 |
Airport Activity
| GA Local: | 14,040 |
| GA Itinerant: | 9,800 |
| Commercial: | |
| Air Taxi: | 2,894 |
| Military: | 200 |
(12-month period ending on 8/5/2010)
Air Safety Institute Resources
Expand Communications Card
Contact Addresses
| ASN Volunteer: | Owner: | Airport Manager: |
| Mark Davis | Norfolk Airport Authority | Ms Terri Wachter |
| P.O. Box 1343 | P.O. Box 1343 | |
| Norfolk, NE 68702-1343 | Norfolk, NE 68702-1343 | |
| 402-841-5130 (Office) | 402-841-5130 (Office) | |
| Contact the ASN Volunteer | ||
| Airport Manager Admin |
