AOPA Airports: Philip Billard Municipal (KTOP)

Satellite
Diagram
Sectional

KTOP (Philip Billard Municipal) airport diagram

Click chart for current METARs and aeronautical charts

Minimum Fuel Prices

Jet-A-Prist	$ 5.04 (full service)
100LL	$ 5.96 (full service)

Runway 04/22

Dimensions:	3002 x 100ft. / 915.0 x 30.5m	Weight Bearing Cap:	Single wheel: 29000 lb
Surface:	asphalt, no surface treatment, in fair condition	Runway Edge Lights:	medium

#	Elev/Hdg	Markings	Approach Lights	Obstructions
04	877.7ft. MSL 44° mag 49° true 0.0% up	basic	No Data	Tree, 72 ft Left of center, 93 ft high, 2,748 ft from end, 27:1 clearance slope

22	878.9ft. MSL 224° mag 229° true 0.0% down	basic	No Data	Tree, 347 ft Right of center, 37 ft high, 1,211 ft from end, 27:1 clearance slope

Runway 13/31

Dimensions:	5099 x 100ft. / 1554.2 x 30.5m	Weight Bearing Cap:	Single wheel: 50000 lb
Surface:	asphalt, no surface treatment, in good condition	Runway Edge Lights:	high

#	Elev/Hdg	Markings	Approach Lights	ILS/LOC	Obstructions
13	879.5ft. MSL 129° mag 134° true 0.1% down	precision	approach: 1400ft/Medium-Intensity/Runway Alignment Indicators	ILS	Tree, 651 ft Right of center, 41 ft high, 1,482 ft from end, 31:1 clearance slope

31	875.1ft. MSL 309° mag 314° true 0.1% up	precision	visual glide slope: 4-Box/Left-Side VASI runway end identifier: REIL is present		Tree, 306 ft Right of center, 31 ft high, 286 ft from end, 2:1 clearance slope

Runway 18/36

Dimensions:	4331 x 75ft. / 1320.1 x 22.9m	Weight Bearing Cap:	Single wheel: 60000 lb
Surface:	asphalt, no surface treatment, in good condition	Runway Edge Lights:	medium

#	Elev/Hdg	Markings	Approach Lights	Obstructions
18	879.5ft. MSL 177° mag 182° true 0.0% up	non-precision	runway end identifier: REIL is present visual glide slope: 4-Box/Left-Side VASI	Trees, Both-Sides, 78 ft high, 2,895 ft from end, 34:1 clearance slope

36	880.2ft. MSL 357° mag 2° true 0.0% down	non-precision	visual glide slope: 4-Box/Right-Side VASI	Trees, 465 ft Left of center, 71 ft high, 1,094 ft from end, 12:1 clearance slope

Business/Service Information

Name		Location	Freq. Monitored	Main Phone
Caris-Midwest Aviation, LLC	Maintenance Sales	On field: CTR		785-357-7580
Hetrick Aviation	Maintenance Sales AOPA WorldPoints	On field: SW		785-354-7055
Kansas Air Center, Inc.	Maintenance $5.96 $5.04 Rentals Sales Flight Training AOPA WorldPoints	On field: W	UNICOM: 122.95	785-234-2602

List Your Business in AOPA Airports

Services at this airport:

Services:
Engine Repair: MajorAirframe Repair: Major
Fuel: 100LL Low-Lead, Jet A
Transportation: Courtesy Car, Public
Rental Cars: Hertz (AOPA Discount Code: CDP 10232)

Expand Nearby restaurants, attractions

Billard Airport 785-232-3669

nmrs 3 mi

Yellow Cab 357-4444

KS National Gaurd Museum 9 mi

Heartland Park Race Track 11 mi

Gage Park 9 mi

Combat Air Museum 9 mi

Kansas Historical Museum 9 mi

Warde Meade Historic Park 5 mi

State Capitol 4 mi

Information above provided by the airport manager.
Search nearby: Hotels | Restaurants

Expand Member Comments

AOPA member comments are are offered unedited and do not necessarily reflect the views of AOPA.

105340660597310/11/2010 7:28:18 AM UTC
Great restaurant. Flew down with my grandson for his birthday when he turned 4 and he hasn't stopped talking about it. Tower is friendly and helpful and the FBO is great also. Highly recommend this for a Saturday morning flight
10072VMULUKA8/29/2010 5:12:33 PM UTC
08/18/2010 -- I always like to have a purpose for my local flights and flight to Topeka did a serve a purpose -- The Breakfast. I and my friend loved the Pancakes and breakfast buffet. Restaurant was busy. Tower is friendly. It does seem like tower is not equiped with a radar. There was quite bit of traffic landing on Saturday morning. I highly recomend this place for early morning breakfast or lunch.
9518061336027/8/2010 3:56:17 PM UTC
My favorite weekend breakfast spot! They have the best blueberry pancakes and a good breakfast buffet. Nice airport, numerous approaches and the tower is very friendly and useful.

Only current AOPA members and business managers can post comments. Make sure you are logged in.

Are you sure you want to delete this comment?

Cancel Delete

Operations & More Information

Lat/Long:	N39 4.1195' / W95 37.3490'39.0686575-95.6224836
Charts:	NACO: Kansas City Sectional
Mag Var:	05E (2000)
ARTCC:	Kansas City (ZKC)
FSS:	Wichita (ICT) 1-800-WXBRIEF
NOTAM Facility:	TOP
Approach/Departure Control Facility
Pattern Altitude:	Light Aircraft: 1681 MSL; Heavy Aircraft: 2381 MSL
Wind Indicator:	Lighted
Seg. Circle:	No
Lighting:	Pilot Activated Lighting: medium intensity: 3 clicks in 3 secs When ATCT Clsd MIRL Rys 04/22 & 18/36 & HIRL Ry 13/31 Preset on Low Intst; to Incr Intst & Actvt MALSR Ry 13; VASI Rys 18 & 31 & REIL Rys 18 & 31 - CTAF

Aircraft & Activity

Based GA Aircraft

Single Engine:	61
Multi Engine:	6
Jets:	0
Helicopters:	0
Gliders:
Ultralights:	3

Airport Activity

GA Local:	21,084
GA Itinerant:	31,356
Commercial:
Air Taxi:	1,622
Military:	3,341

(12-month period ending on 8/31/2010)

Air Safety Institute Resources

Accident Reports

Expand Communications Card

Type	Location/Call	Freq./Phone
WX	Topeka	121.275T (785-234-1591)
CTAF	Topeka	118.7
Ground Control Clearance-Delivery	Topeka	121.9
Tower	Topeka	118.7
UNICOM	Topeka	122.95

Expand Navaids

ID	Type	Freq	Radial	Distance
TO	NDB	365.0	131	4 nm
TO	NDB	521.0	131	4 nm
TOP	VORTAC	117.8	215	5 nm
FOE	VOT	111.0	017	7 nm
FOE	TACAN	.0	009	8 nm
DO	NDB	236.0	253	42 nm
DO	NDB	359.0	253	42 nm
MCI	VORTAC	113.3	248	43 nm
OJC	VOR/DME	113.0	283	44 nm
UKL	NDB	245.0	001	46 nm
RBA	VOR/DME	108.2	187	48 nm
MKC	VOT	108.6	266	48 nm
RIS	VOR/DME	111.4	262	48 nm
MHK	VOR/DME	110.2	091	49 nm

Attendance:	Attended Year-round, 7 Days a Week,0600-2200
Tower:	Air Traffic Control Tower, 12 hrs/day, everyday, year-roundTower Hrs: 0700-1900
Elevation:	881 ft (268.5 m) (Surveyed)
Location:	3.00 mi. NE of Topeka
Beacon:	Present (white-green)
Runways:	04/22, 13/31, 18/36 Longest paved runway: 5099 ft
Fees:	Hangar

APD	AIRPORT DIAGRAM (changed)	143.6 KB
HOT	HOT SPOT	12 KB
IAP	ILS OR LOC RWY 13 (changed)	372.4 KB
IAP	RNAV (GPS) RWY 04 (changed)	232.2 KB
IAP	RNAV (GPS) RWY 13 (changed)	247.6 KB
IAP	RNAV (GPS) RWY 18 (changed)	271.3 KB
IAP	RNAV (GPS) RWY 22 (changed)	255.5 KB
IAP	RNAV (GPS) RWY 31 (changed)	237.1 KB
IAP	RNAV (GPS) RWY 36 (changed)	239.5 KB
IAP	LOC BC RWY 31 (changed)	256.8 KB
IAP	VOR RWY 22 (changed)	238.1 KB
MIN	TAKE-OFF MINIMUMS	77.9 KB
MIN	ALTERNATE MINIMUMS	20.8 KB

ASN Volunteer:	Owner:	Airport Manager:
Timothy Vice	Metro. Topeka Airport Authority	Eric M. Johnson
	Forbes Field, B-19053	Forbes Field, Po Box 19053
	Topeka, KS 66619	Topeka, KS 66619
	785-862-2362 (Office)	785-862-2362 (Office)
Contact the ASN Volunteer

Philip Billard Municipal

Overview

Expand Instrument Approach Procedures
