FAA Information Effective: 5/2/2013
AOPA members save at 3,000+ GA airports.Book Now!
KUGNCivil
Public Use
Public Use
Waukegan Regional
Chicago/Waukegan, IL
Phone: 847-244-0055
Nearby airports
Operations | Communications | Weather |
Runways |
Comments |
Remarks |
Procedures | Services, Businesses & FBOsKneeboard Format
Overview
| Attendance: |
Attended Year-round, 7 Days a Week,All |
| Tower: | Air Traffic Control Tower, 16 hrs/day, everyday, year-round |
| Elevation: | 727 ft (221.6 m) (Surveyed) |
| Location: | 35.00 mi. N of Chicago/Waukegan |
| Beacon: | Present (white-green) |
| Approaches: | ILS, RNAV, GPS |
| Runways: | 05/23, 14/32
Longest paved runway: 6000 ft |
| Fees: | No data |
Expand Additional Remarks
Runway 05/23
| Dimensions: | 6000 x 150ft. / 1828.8 x 45.7m | Weight Bearing Cap: | Single wheel: 95000 lb |
| Surface: | asphalt, porous friction course, in good condition | Runway Edge Lights: | high |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 05 | 725.0ft. MSL 51° mag 48° true 0.0% down |  | non-precision | visual glide slope: 4-Box/Left-Side VASI | Road, 502 ft Left of center, 12 ft high, 281 ft from end, 6:1 clearance slope | |||||
| 23 | 723.0ft. MSL 231° mag 228° true 0.0% up |  | precision | visual glide slope: 4-Box/Left-Side VASI approach: 1400ft/Medium-Intensity/Runway Alignment Indicators | ILS | Tree, 52 ft Left of center, 15 ft high, 1,038 ft from end, 50:1 clearance slope | ||||
Runway 14/32
| Dimensions: | 3751 x 75ft. / 1143.3 x 22.9m | Weight Bearing Cap: | Single wheel: 16000 lb |
| Surface: | asphalt, no surface treatment, in good condition | Runway Edge Lights: | medium |
| # | Elev/Hdg | Tr. Pat. | Markings | Approach Lights | TD Point | ILS/LOC | Obstructions | Comments/Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 14 | 727.2ft. MSL 147° mag 144° true 0.4% down | | basic | visual glide slope: 4-Box/Left-Side VASI | 500' Disp Threshold | Tree, 193 ft Left of center, 54 ft high, 378 ft from end, 3:1 clearance slope | Apch Ratio is 16:1 at Dsplcd Thld | |||
| 32 | 711.5ft. MSL 327° mag 324° true 0.4% up | | basic | No Data | Tree, 363 ft Right of center, 60 ft high, 1,445 ft from end, 20:1 clearance slope | |||||
Business/Service Information
| Name | Location | Freq. Monitored | Main Phone | |
|---|---|---|---|---|
| Landmark Aviation |
| On field: CTR |
UNICOM: 121.65 ARINC: 131.85 | 800-922-3835 |
| Skill Aviation |
| On field: E | 847-599-9955 | |
| Stick & Rudder Flying Club |
| On field: NE | 847-249-5190 | |
| Waukegan Avionics and Maintenance |
| On field: SW | 847-336-6075 |
Services at this airport:
Services:Engine Repair: MajorAirframe Repair: MajorBulk Oxygen: High/Low
Fuel: 100LL Low-Lead, Jet A
Transportation: Limousine, Courtesy Car
Rental Cars:
| Hertz |
Customs: International Landing Rights
Expand Nearby restaurants, attractions
Operations & More Information
| Lat/Long: | N42 25.3296' / W87 52.0744' |
| Charts: | NACO:
Chicago Sectional |
| Mag Var: | 03W (2000) |
| ARTCC: | Chicago (ZAU) |
| FSS: | Kankakee (IKK) 1-800-WXBRIEF |
| NOTAM Facility: | UGN |
| Approach/Departure Control Facility | ORD |
| Pattern Altitude: | Rotorcraft: 1427 MSL; Light Aircraft: 1527 MSL; Heavy Aircraft: 2200 MSL |
| Wind Indicator: | Lighted |
| Seg. Circle: | Yes |
| Lighting: | Pilot Activated Lighting:
|
Aircraft & Activity
Based GA Aircraft
| Single Engine: | 88 |
| Multi Engine: | 20 |
| Jets: | 39 |
| Helicopters: | 2 |
| Gliders: | |
| Ultralights: |
Airport Activity
| GA Local: | 24,476 |
| GA Itinerant: | 25,263 |
| Commercial: | |
| Air Taxi: | 3,120 |
| Military: | 957 |
(12-month period ending on 7/31/2012)
Air Safety Institute Resources
Expand Communications Card
Contact Addresses
| ASN Volunteer: | Owner: | Airport Manager: |
| Barry Mc Kenna | Waukegan Port District | Jim Stanczak |
| Po Box 620 | 3500 N. Mc Aree Rd | |
| Waukegan, IL 60079 | Waukegan, IL 60087 | |
| 847-244-3133 (Office) | 847-244-0055 (Office) | |
| Contact the ASN Volunteer | ||
| Airport Manager Admin |
