FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 09 | 27 |
Elevation: | 108.8 ft | 106.1 ft |
Heading: | 088° magnetic 104° true | 268° magnetic 284° true |
Gradient: | 0.09% down | 0.09% up |
Traffic Pattern: | Right Pattern | Not provided. Assume LEFT traffic pattern |
Markings: | basic, in Fair condition | basic, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, Both-Sides, 81 ft high, 1,815 ft from end, 19:1 clearance slope | Tree, 91 ft Left ft of center, 76 ft high, 1,939 ft from end, 22:1 clearance slope |
Comments: | Rwy 09 are Baffled Byd 6.5 Deg Left of Rwy Cntrln Due to Trrn. FAA | Rwy 27 are Baffled Byd 6.5 Deg Right of Rwy Cntrln Due to Trrn. FAA |
Designator: | H1 |
Elevation: | 120 ft |
Markings: | n/a |
Obstructions: | n/a |
Comments: | n/a |
Runway: | Applies to: | Approach/Departure: | Text: |
---|---|---|---|
09 | All Aircraft | Departure | Fly runway heading to 700' msl, abreast of HIghway intersection before turns. Departures to West, extend crosswind turn to clear downwind traffic pattern, above pattern altitude, before turning West. |
27 | All Aircraft | Departure | Fly runway heading to golf course & 700' msl before turns. Departures to South & East, left hand turn at golf course, extend crosswind leg until well South over Discovery Bay. |
All | All Aircraft | Departure | On departures: Reduce power & change propeller pitch as soon as safety and performance permits |
All | All Aircraft | Approach | On approaches: Avoid long, low excess power. Remain at or above indicated glide slope on final approaches. |
All | Rotorcraft | Both | Same procedures as fixed wing aircraft. Stay East of segmented circle – windsock on approach to helipad landing area. Do not over fly any aircraft on taxiways or parked aircraft. |
All Aircraft 1000 MSL
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
AWOS-3P | 119.025T (360) 379-1199 | ||
Clearance Delivery Phone | (360) 257-3310 | Whidbey Approach | |
CTAF | 123.0 | ||
UNICOM | 123.0 |
Name: | Operated by: | Site: | Facing: |
---|---|---|---|
Jefferson County International Webcam #1 | Airport | AWOS tower | E |
Jefferson County International Webcam #2 | Airport | AWOS Tower | N |
Jefferson County International Webcam #3 | Airport | AWOS Tower | W |
