FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 14 | 32 |
Elevation: | 121.4 ft | 119 ft |
Heading: | 139° magnetic 123° true | 319° magnetic 303° true |
Gradient: | 0.07% down | 0.07% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | basic, in Good condition | non-precision, in Good condition |
Approach Lighting: | n/a |
|
Displaced Threshold: | 509 ft | 237 ft |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, Both-Sides, 50 ft high, 1,200 ft from end, 20:1 clearance slope | Trees, Both-Sides, 50 ft high, 800 ft from end, 12:1 clearance slope |
Comments: | Apch Ratio 34:1 to Dthr. FAA | Apch Ratio 34:1 to Dthr. FAA |
Designator: | 04 | 22 |
Elevation: | 116.8 ft | 122.9 ft |
Heading: | 044° magnetic 028° true | 224° magnetic 208° true |
Gradient: | 0.3% up | 0.3% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | none | none |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 42 ft high, 830 ft from end, 20:1 clearance slope | Trees, 100 ft high, 600 ft from end, 6:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/109 | 06/14/2025 0437 | 06/29/2025 0337 | OBST TOWER LGT (ASR 1220607) 420533.10N0711815.40W (7.2NM NW 1B9) 503.0FT (218.8FT AGL) U/S |
5/4415 | 06/13/2025 1936 | IAP MANSFIELD MUNI, MANSFIELD, MA.
COPTER RNAV (GPS) Y RWY 14, AMDT 1...
DISREGARD NOTE: DESCENT ANGLE 5.70/… Show more | |
06/046 | 06/07/2025 0431 | 06/22/2025 0331 | OBST TOWER LGT (ASR 1232361) 420532.50N0711810.50W (7.2NM NW 1B9) 464.9FT (216.9FT AGL) U/S |
02/163 | 02/13/2025 0909 | 08/01/2025 2359 | OBST TOWER LGT (ASR 1006021) 420030.00N0710301.00W (6.5NM E 1B9) 322.2FT (248.0FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 124.1 | Boston | |
AWOS-3PT | 118.675T (774) 372-2047 | ||
Clearance Delivery Phone | (603) 594-5554 | Boston Approach | |
CTAF | 123.0 | ||
UNICOM | 123.0 | ||
WOONS STAR | 120.6 | Boston |
