FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 09 | 27 |
Elevation: | 770.4 ft | 777.1 ft |
Heading: | 094° magnetic 090° true | 274° magnetic 270° true |
Gradient: | 0.1% up | 0.1% down |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | ILS |
Obstructions: | Trees, Both-Sides, 40 ft high, 1,050 ft from end, 21:1 clearance slope | Trees, Both-Sides, 69 ft high, 2,645 ft from end, 35:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 18 | 36 |
Elevation: | 777.2 ft | 771.8 ft |
Heading: | 176° magnetic 172° true | 356° magnetic 352° true |
Gradient: | 0.14% down | 0.14% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Poor condition | non-precision, in Poor condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, Both-Sides, 40 ft high, 1,200 ft from end, 25:1 clearance slope | Trees, Both-Sides, 62 ft high, 1,200 ft from end, 16:1 clearance slope |
Comments: | Faded. FAA | 7 Ft Brush L & R of Cntrln 100 Ft Fm Thr. FAA Faded. FAA Vasi Unusbl 7 Deg Left & Right of Cntrln. FAA |
Designator: | 08 | 26 |
Elevation: | 769.3 ft | 773.3 ft |
Heading: | 093° magnetic 089° true | 273° magnetic 269° true |
Gradient: | 0.16% up | 0.16% down |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | n/a | n/a |
Comments: | White Corner Mkrs. FAA | White Corner Mkrs. FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/004 | 06/13/2025 0455 | NAV ILS RWY 27 LOC/GP U/S | |
05/001 | 05/01/2025 1246 | 08/29/2025 1246 | OBST TOWER LGT (ASR 1222556) 414356.90N0860450.00W (3.5NM WNW EKM) 1024.9FT (250.0FT AGL) U/S |
06/001 | 06/09/2025 0441 | 06/23/2025 2359 | OBST TOWER LGT (ASR 1031004) 414457.60N0860710.50W (5.5NM WNW EKM) 1340.2FT (535.1FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 118.55 | South Bend | |
AWOS-3 | 124.475T (574) 264-9002 | Elkhart | |
Clearance Delivery | 121.8 | Elkhart | |
Clearance Delivery | 119.7 | WHEN ELKHART TWR CLSD | South Bend |
CTAF | 119.5 | Elkhart | |
Ground Control | 121.8 | Elkhart | |
Tower | 119.5 | Elkhart | |
UNICOM | 122.95 | Elkhart |
