FAA Information Effective: May 15, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 05 | 23 |
Elevation: | 107.9 ft | 122.2 ft |
Heading: | 050° magnetic 046° true | 230° magnetic 226° true |
Gradient: | 0.29% up | 0.29% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 230 ft Left ft of center, 35 ft high, 1,335 ft from end, 32:1 clearance slope | Trees, 200 ft Left ft of center, 23 ft high, 770 ft from end, 24:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 09L | 27R |
Elevation: | 116.9 ft | 114.5 ft |
Heading: | 091° magnetic 087° true | 271° magnetic 267° true |
Gradient: | 0.05% down | 0.05% up |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | non-precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Tree, 110 ft Right ft of center, 62 ft high, 2,290 ft from end, 34:1 clearance slope | Tree, 240 ft Left ft of center, 28 ft high, 1,130 ft from end, 34:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 09R | 27L |
Elevation: | 112.3 ft | 111.6 ft |
Heading: | 091° magnetic 087° true | 271° magnetic 267° true |
Gradient: | 0.02% down | 0.02% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | basic, in Fair condition | basic, in Fair condition |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 175 ft Left ft of center, 56 ft high, 1,900 ft from end, 31:1 clearance slope | Trees, 30 ft Right ft of center, 40 ft high, 1,000 ft from end, 20:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
5/5914 | 05/05/2025 1528 | IAP BARTOW EXEC, BARTOW, FL.
VOR RWY 9L, AMDT 2G...
S-9L MDA 620/HAT 495 ALL CATS, VIS CATS C/D 1 3/8. CIRC… | |
3/9117 | 08/22/2023 1537 | IAP BARTOW EXEC, BARTOW, FL.
RNAV (GPS) RWY 23, ORIG-D...
LNAV MDA 600/HAT 476 ALL CATS.
WHEN LOCAL ALTIMETE… | |
05/004 | 05/25/2025 0506 | 07/09/2025 0506 | OBST TOWER LGT (ASR 1056614) 275248.00N0814857.00W (4.2NM SSW BOW) 547.2FT (430.1FT AGL) U/S |
3/4827 | 10/12/2023 1349 | IAP BARTOW EXEC, BARTOW, FL.
RNAV (GPS) RWY 27R, AMDT 1C...
LPV DA NA ALL CATS.
LNAV/VNAV DA NA ALL CATS.
23… | |
3/4826 | 10/12/2023 1349 | IAP BARTOW EXEC, BARTOW, FL.
RNAV (GPS) RWY 5, ORIG-D...
LPV DA NA ALL CATS.
LNAV/VNAV DA NA ALL CATS.
CHANG… | |
5/5913 | 05/05/2025 1528 | IAP BARTOW EXEC, BARTOW, FL.
RNAV (GPS) RWY 9L, AMDT 1D...
LNAV MDA 620/HAT 495 ALL CATS, VIS CATS C/D 1 3/8… | |
05/001 | 05/05/2025 1312 | 06/19/2025 1312 | OBST TOWER LGT (ASR 1056607) 274456.00N0815331.00W (13.2NM SSW BOW) 570.2FT (430.1FT AGL) U/S |
04/003 | 04/30/2025 1551 | SVC AUTOMATED WX BCST SYSTEM WX U/S | |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach(S) Departure(S) | 119.9 | Tampa | |
Approach/Departure | 120.65 | Tampa | |
AWOS-3 | 123.775T (863) 533-9004 | Bartow | |
CTAF | 121.2 | Bartow | |
Emergency | 121.5 | Bartow | |
Ground Control | 121.9 | Bartow | |
Tower | 121.2 | Bartow | |
Tower(S) | 121.5R | Bartow | |
UNICOM | 122.95 | Bartow |
