FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 09 | 27 |
Elevation: | 6.6 ft | 7.8 ft |
Heading: | 096° magnetic 091° true | 276° magnetic 271° true |
Gradient: | 0.03% up | 0.03% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Road, Both-Sides, 18 ft high, 350 ft from end, 8:1 clearance slope | Brush, 95 ft Left ft of center, 15 ft high, 375 ft from end, 11:1 clearance slope |
Comments: | Rwy 09 Aprch Ratio 22:1 to Dthr. FAA | n/a |
Designator: | 18 | 36 |
Elevation: | 6.1 ft | 5.7 ft |
Heading: | 185° magnetic 180° true | 365° magnetic 360° true |
Gradient: | 0.02% down | 0.02% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | 192 ft | 819 ft |
ILS/LOC: | n/a | n/a |
Obstructions: | Building, 85 ft Right ft of center, 15 ft high, 104 ft from end, 6:1 clearance slope | Fence, Both-Sides, 7 ft high, 15 ft from end, 2:1 clearance slope |
Comments: | 18/36 Dthr Mkd with Green Pipes. FAA 18/36 Mkd with White Pipes Every 200 Ft. FAA Rwy 18 Approach Ratio 20:1 to Dthr. FAA | Rwy 36 Approach Ratio 22:1 to Dthr. FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
05/011 | 05/16/2025 1829 | 11/16/2025 2359 | OBST TOWER LGT (ASR 1029656) 285235.90N0823125.30W (2.7NM ENE CGC) 370.1FT (299.9FT AGL) U/S |
07/002 | 07/02/2025 2341 | 10/30/2025 2341 | OBST TOWER LGT (ASR 1004335) 284257.00N0823234.60W (9.2NM S CGC) 283.1FT (271.0FT AGL) U/S |
4/9027 | 03/20/2024 1312 | IAP CRYSTAL RIVER-CAPT TOM DAVIS FLD, CRYSTAL RIVER, FL.
RNAV (GPS) RWY 9, AMDT 1C...
LP MDA MINIMUMS NA.
24… | |
07/007 | 07/21/2025 1503 | 11/18/2025 1503 | OBST TOWER LGT (ASR 1266599) 285117.90N0823436.80W (0.8NM S CGC) 156.8FT (149.9FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 118.6 | Jacksonville | |
AWOS-3 | 118.325T (352) 563-6600 | ||
Clearance Delivery Phone | (904) 741-0284 | Jacksonville Approach | |
CTAF | 122.725 | ||
UNICOM | 122.725 |
