FAA Information Effective: May 15, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 09 | 27 |
Elevation: | 668.8 ft | 643.1 ft |
Heading: | 090° magnetic 085° true | 270° magnetic 265° true |
Gradient: | 0.56% down | 0.56% up |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | non-precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | n/a | Tree, 322 ft Right ft of center, 56 ft high, 1,231 ft from end, 18:1 clearance slope |
Comments: | Preferred Ldg Rwy 2300-0700. FAA | Preferred Tkof Rwy 2300-0700. FAA |
Designator: | 04 | 22 |
Elevation: | 646 ft | 640.2 ft |
Heading: | 045° magnetic 040° true | 225° magnetic 220° true |
Gradient: | 0.45% down | 0.45% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, Both-Sides, 100 ft high, 2,000 ft from end, 20:1 clearance slope | Tree, Both-Sides, 95 ft high, 1,900 ft from end, 20:1 clearance slope |
Comments: | 3 Ft Yellow Cones. FAA | 3 Ft Yellow Cones. FAA |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
AWOS-3P | 120.0T (231) 237-9703 | ||
Clearance Delivery Phone | (651) 463-5588 | Minneapolis ARTCC | |
CTAF | 122.8 | ||
UNICOM | 122.8 |
Name: | Operated by: | Site: | Facing: |
---|---|---|---|
Island Airways Webcam #1 | Other | Charlevoix Ramp | N |
Island Airways Webcam #2 | Other | Charlevoix Loading Dock | N |
