FAA Information Effective: May 15, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 02 | 20 |
Elevation: | 912.6 ft | 903.7 ft |
Heading: | 021° magnetic 019° true | 201° magnetic 199° true |
Gradient: | 0.13% down | 0.13% up |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | precision, in Good condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | ILS/DME | n/a |
Obstructions: | Railroad, 650 ft Right ft of center, 21 ft high, 1,237 ft from end, 50:1 clearance slope | n/a |
Comments: | n/a | n/a |
Designator: | 09 | 27 |
Elevation: | 911.4 ft | 911.7 ft |
Heading: | 092° magnetic 090° true | 272° magnetic 270° true |
Gradient: | 0.01% up | 0.01% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Good condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | n/a | Tree, 170 ft Right ft of center, 40 ft high, 1,464 ft from end, 31:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
5/9000 | 03/04/2025 1428 | ODP DE KALB TAYLOR MUNI, DE KALB, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4A...
TAKEOF… Show more | |
05/008 | 05/19/2025 1155 | 05/23/2025 2200 | AD AP ALL SFC WIP MOWING DLY SR-2200 |
Runway: | Applies to: | Approach/Departure: | Text: |
---|---|---|---|
All | All Aircraft | Both | Avoid overflight of town of Cortland on apch ry 27; avoid alt blo 300'AGL one mi out; on apch to ry 2 contingent upon safety & as conds will allow; rcmd for courtesy to residential occupants |
Light Aircraft 1914 MSL
Turbine Aircraft 2414 MSL
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 133.5 | Chicago | |
AWOS-3 | 119.075T (815) 748-2350 | ||
Clearance Delivery Phone | (847) 289-0926 | Chicago Approach | |
CTAF | 122.7 | ||
UNICOM | 122.7 |
