FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 05 | 23 |
Elevation: | 141.6 ft | 141.2 ft |
Heading: | 049° magnetic 045° true | 229° magnetic 225° true |
Gradient: | 0.01% down | 0.01% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Fence, 250 ft Left ft of center, 5 ft high, 205 ft from end, 1:1 clearance slope | Trees, 65 ft Left ft of center, 41 ft high, 1,245 ft from end, 25:1 clearance slope |
Comments: | Rwy 05 Approach Slope 16:1 to Approach End of Runway Due to 33 Ft Trees 515 Ft Fm Rwy End and 150 Ft Left . FAA | n/a |
Designator: | 11 | 29 |
Elevation: | 143 ft | 141.1 ft |
Heading: | 107° magnetic 103° true | 287° magnetic 283° true |
Gradient: | 0.05% down | 0.05% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Fair condition | basic, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Power-Line, 70 ft Left ft of center, 43 ft high, 1,430 ft from end, 28:1 clearance slope | Fence, 250 ft Left ft of center, 5 ft high, 215 ft from end, 3:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/006 | 06/13/2025 2107 | 10/11/2025 2107 | OBST TOWER LGT (ASR 1004342) 280746.00N0813940.00W (6.4NM NE GIF) 454.7FT (320.9FT AGL) U/S |
03/004 | 03/21/2025 1151 | 12/31/2025 2359 | AD AP ABN NOT STD WHITE ONLY |
5/1633 | 05/15/2025 1910 | IAP WINTER HAVEN RGNL, WINTER HAVEN, FL.
RNAV (GPS) RWY 11, ORIG-C...
TAA STRAIGHT-IN FROM 017/30 CW 197/30 … Show more | |
07/009 | 07/24/2025 1519 | 10/24/2025 2359 | OBST TOWER LGT (ASR 1050260) 281738.00N0814956.00W (14.3NM NNW GIF) 390.4FT (239.5FT AGL) U/S |
07/008 | 07/17/2025 1702 | 07/31/2025 2359 | AD AP MOGAS FUEL NOT AVBL |
06/010 | 06/28/2025 2005 | 10/26/2025 2005 | OBST TOWER LGT (ASR 1252625) 280118.10N0814049.80W (4.5NM ESE GIF) 339.9FT (205.1FT AGL) U/S |
07/005 | 07/10/2025 1532 | 10/09/2025 0400 | OBST TOWER LGT (ASR 1012261) 281102.20N0814910.70W (7.9NM NNW GIF) 480.0FT (298.9FT AGL) U/S |
07/010 | 07/25/2025 1348 | 08/15/2025 2100 | TWY F LGT U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach(S) Departure(S) | 119.9 | Tampa | |
Approach/Departure | 120.65 | Tampa | |
ASOS | 133.675T (863) 956-2097 | ||
CTAF | 123.05 | ||
UNICOM | 123.05 |
