FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 10 | 28 |
Elevation: | 598.7 ft | 597.3 ft |
Heading: | 097° magnetic 090° true | 277° magnetic 270° true |
Gradient: | 0.03% down | 0.03% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | ILS/DME |
Obstructions: | Tree, 740 ft Left ft of center, 83 ft high, 2,060 ft from end, 22:1 clearance slope | Trees, 300 ft Left ft of center, 45 ft high, 629 ft from end, 9:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 05 | 23 |
Elevation: | 600.8 ft | 597.9 ft |
Heading: | 052° magnetic 045° true | 232° magnetic 225° true |
Gradient: | 0.1% down | 0.1% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | basic, in Good condition | basic, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | 119 ft | 129 ft |
ILS/LOC: | n/a | n/a |
Obstructions: | Fence, 120 ft Right ft of center, 6 ft high, 200 ft from end, 1:1 clearance slope | Road, 126 ft Right ft of center, 15 ft high, 210 ft from end, 1:1 clearance slope |
Comments: | Apch Ratio 22:1 to Dthr Ovr 15 Ft Road, 330 Ft Dist, 158 Ft R. FAA | 2 Ft Conc Culvert, 100 Ft Dist, 80 Ft L; -15 Ft Ditch, Acrs Approach End. FAA Apch Ratio 22:1 to Dthr Ovr 15 Ft Road, 330 Ft Dist, 158 Ft R. FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
05/011 | 05/30/2024 1958 | 07/31/2027 2359 | OBST STACK LGT (ASN 2019-AGL-1793-OE) 432845N0835416W (3.3NM NW HYX) 693FT (110FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 120.95 | Great Lakes | |
AWOS-3PT | 118.325T (989) 752-3408 | ||
Clearance Delivery Phone | (269) 459-3345 | Great Lakes Approach | |
Clearance Delivery Phone | (440) 774-0224 | When Approach Closed | Cleveland ARTCC |
CTAF | 122.8 | ||
UNICOM | 122.8 |
