FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 18 | 36 |
Elevation: | 949.4 ft | 971.1 ft |
Heading: | 178° magnetic 182° true | 0-2° magnetic 002° true |
Gradient: | 0.33% up | 0.33% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | ILS/DME | n/a |
Obstructions: | Pole, 400 ft Right ft of center, 15 ft high, 675 ft from end, 31:1 clearance slope | n/a |
Comments: | n/a | n/a |
Designator: | 13 | 31 |
Elevation: | 947.2 ft | 976.7 ft |
Heading: | 134° magnetic 138° true | 314° magnetic 318° true |
Gradient: | 0.45% up | 0.45% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | 388 ft | 299 ft |
ILS/LOC: | ILS | n/a |
Obstructions: | Tree, 490 ft Right ft of center, 36 ft high, 825 ft from end, 17:1 clearance slope | Tree, 300 ft Left ft of center, 47 ft high, 1,200 ft from end, 21:1 clearance slope |
Comments: | Apch Ratio from Dsplcd Thr 33:1 FAA | Apch Ratio from Dsplcd Thr 32:1 FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/003 | 06/03/2025 2001 | 07/03/2025 2359 | OBST TOWER LGT (ASR 1032005) 371315.00N0944226.00W (10.8NM WNW JLN) 2016.7FT (1127.0FT AGL) U/S |
05/060 | 05/27/2025 2100 | 11/01/2025 2056 | TWY C BTN APCH END RWY 31 AND APCH END RWY 36 CLSD |
06/012 | 06/15/2025 0813 | 10/13/2025 0813 | OBST TOWER LGT (ASR 1290444) 372002.60N0942907.20W (10.9NM NE JLN) 1211.0FT (259.8FT AGL) U/S |
01/078 | 01/29/2025 0146 | 06/27/2025 0145 | TWY C, C1, D, D1, E, E1 ELEVATED RWY GUARD LGT NOT STD |
06/006 | 06/09/2025 1425 | 06/24/2025 1325 | OBST TOWER LGT (ASR 1227864) 370506.80N0942018.60W (8.7NM ESE JLN) 1302.2FT (205.1FT AGL) U/S |
05/037 | 05/20/2025 0852 | 07/04/2025 0851 | OBST TOWER LGT (ASR 1249650) 365954.00N0942835.80W (9.3NM S JLN) 1353.0FT (265.1FT AGL) U/S |
06/010 | 06/14/2025 1102 | 07/29/2025 1101 | OBST TOWER LGT (ASR 1319356) 371726.99N0942926.32W (8.3NM NE JLN) 1153FT (265FT AGL) U/S |
06/013 | 06/16/2025 0517 | 07/01/2025 0417 | OBST TOWER LGT (ASR 1267896) 370847.20N0943320.10W (2.8NM W JLN) 1181.1FT (245.1FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
ASOS | (417) 623-8892 | Joplin | |
ATIS | 120.85 | Joplin | |
CTAF | 119.8 | Joplin | |
Ground Control | 121.6 | Joplin | |
Tower | 119.8 | Joplin | |
UNICOM | 122.95 | Joplin |
