FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 03 | 21 |
Elevation: | 1,057 ft | 1,044.1 ft |
Heading: | 036° magnetic 040° true | 216° magnetic 220° true |
Gradient: | 0.17% down | 0.17% up |
Traffic Pattern: | Right Pattern | Left Pattern |
Markings: | precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | 370 ft |
ILS/LOC: | ILS | n/a |
Obstructions: | Trees, 537 ft Left ft of center, 105 ft high, 3,996 ft from end, 36:1 clearance slope | Trees, 259 ft Right ft of center, 86 ft high, 2,124 ft from end, 23:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 13 | 31 |
Elevation: | 1,066.1 ft | 1,051.2 ft |
Heading: | 138° magnetic 142° true | 318° magnetic 322° true |
Gradient: | 0.3% down | 0.3% up |
Traffic Pattern: | Left Pattern | Right Pattern |
Markings: | basic, in Good condition | basic, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Pole, 392 ft Left ft of center, 237 ft high, 7,174 ft from end, 29:1 clearance slope | Tree, 624 ft Left ft of center, 93 ft high, 1,607 ft from end, 15:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
07/025 | 07/10/2025 0524 | 08/24/2025 0523 | OBST TOWER LGT (ASR 1012361) 390145.00N0962927.00W (10.8NM SE MHK) 1798.9FT (320.9FT AGL) U/S |
06/049 | 06/23/2025 2250 | 10/21/2025 2250 | OBST TOWER LGT (ASR 1205385) 390351.60N0964039.80W (4.6NM S MHK) 1634.2FT (309.1FT AGL) U/S |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 121.25 | Marshall Aaf Gca | |
ASOS | 119.075T (785) 537-1035 | Manhattan | |
CTAF | 118.55 | Manhattan | |
Ground Control | 121.85 | Manhattan | |
Tower | 118.55 | Manhattan |
