FAA Information Effective: May 15, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 17 | 35 |
Elevation: | 216.1 ft | 266.4 ft |
Heading: | 172° magnetic 157° true | 352° magnetic 337° true |
Gradient: | 0.54% up | 0.54% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | 336 ft | 850 ft |
ILS/LOC: | ILS/DME | ILS/DME |
Obstructions: | Pole, 125 ft Left ft of center, 71 ft high, 2,600 ft from end, 34:1 clearance slope | Building, 75 ft Right ft of center, 53 ft high, 3,025 ft from end, 50:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 06 | 24 |
Elevation: | 220.9 ft | 241.5 ft |
Heading: | 057° magnetic 042° true | 237° magnetic 222° true |
Gradient: | 0.27% up | 0.27% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | 442 ft | n/a |
ILS/LOC: | ILS | n/a |
Obstructions: | Trees, 470 ft Left ft of center, 61 ft high, 2,667 ft from end, 40:1 clearance slope | Trees, 75 ft Left ft of center, 52 ft high, 1,500 ft from end, 25:1 clearance slope |
Comments: | Engineered Materials Arresting System (Emas) 300 Ft in Length by 170 Ft in Width Lctd At the Der 06. FAA Papi Unusbl Byd 6 Degs R of Cntrln. FAA | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/002 | 06/01/2025 0814 | 06/02/2025 0814 | RWY 06 FICON 5/5/5 100 PCT WET OBS AT 2506010814. |
06/001 | 06/01/2025 0245 | NAV DME NOT MNT | |
05/118 | 05/31/2025 2008 | NAV ILS RWY 06 GP U/S | |
01/299 | 01/31/2025 1300 | 01/01/2026 0100 | AIRSPACE UAS WI AN AREA DEFINED AS .5NM RADIUS OF 424321N0713432W (4.5NM SW ASH) SFC-400FT AGL DLY 1300-0100 |
05/050 | 05/13/2025 0924 | 06/27/2025 2036 | OBST TOWER LGT (ASN 2020-ANE-5582-OE) 425432N0712460W (1.7NM SSE MHT) 365FT (40FT AGL) U/S |
05/108 | 05/30/2025 1857 | RWY 06 RVRR U/S | |
05/111 | 05/30/2025 1921 | RWY 24 RVRT U/S | |
03/011 | 03/05/2025 1529 | NAV ILS RWY 06 OM U/S | |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 124.9 | Boston | |
ASOS | 119.55T (603) 626-6902 | Manchester | |
ATIS | 119.55 | Manchester | |
CLASS C | 124.9 | MANCHESTER/CONCORD AREA | Boston |
CLASS C | 134.75 | NH LAKES REGION | Boston |
CLASS C | 125.05 | NH SEACOAST AREA | Boston |
Clearance Delivery | 135.9 | Manchester | |
Emergency | 121.5 | Manchester | |
Ground Control | 121.9 | Manchester | |
Tower | 121.3 | Manchester | |
UNICOM | 122.95 | Manchester |
