FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 01 | 19 |
Elevation: | 748.4 ft | 756.9 ft |
Heading: | 012° magnetic 013° true | 192° magnetic 193° true |
Gradient: | 0.12% up | 0.12% down |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Left Pattern |
Markings: | non-precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | 299 ft | 301 ft |
ILS/LOC: | n/a | ILS/DME |
Obstructions: | Tree, 571 ft Right ft of center, 38 ft high, 747 ft from end, 20:1 clearance slope | Road, 150 ft Left ft of center, 20 ft high, 700 ft from end, 25:1 clearance slope |
Comments: | Engineered Materials Arresting Sysytem (Emas) 263 Ft in Length by 170 Ft in Width Lctd At the Der 01. FAA | Engineered Materials Arresting Sysytem (Emas) 287 Ft in Length by 170 Ft in Width Lctd At the Der 19. FAA Road & Fence 0-200' Fm Thr. FAA Ry19 Malsf Augmented with Rail. FAA |
Designator: | 04 | 22 |
Elevation: | 742.7 ft | 743.2 ft |
Heading: | 037° magnetic 038° true | 217° magnetic 218° true |
Gradient: | 0.01% up | 0.01% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | 500 ft | 699 ft |
ILS/LOC: | ILS/DME | n/a |
Obstructions: | Berm, 125 ft Left ft of center, 20 ft high, 450 ft from end, 12:1 clearance slope | Railroad, 100 ft Left ft of center, 37 ft high, 225 ft from end |
Comments: | Apch Ratio At Dsplcd Thr 47:1. FAA | Apch Ratio At Dsplcd Thr 24:1. FAA Road & Rr 0-200' Fm Thr. FAA Unusbl Byd 8 Degs Left of Crs. FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
12/037 | 12/04/2024 2242 | 03/19/2026 0400 | OBST CRANE (ASN 2024-ACE-4452-OE) 390635N0943523W (0.8NM S MKC) 1086FT (300FT AGL) FLAGGED AND LGTD |
5/5222 | 07/12/2025 1800 | IAP KANSAS CITY DOWNTOWN/WHEELER FLD, KANSAS CITY, MO.
RNAV (GPS) Z RWY 19, AMDT 2...
LNAV/VNAV DA# 1139/HAT… Show more | |
5/5224 | 07/12/2025 1800 | IAP KANSAS CITY DOWNTOWN/WHEELER FLD, KANSAS CITY, MO.
RNAV (GPS) RWY 4, AMDT 3D...
LPV CATS A/B/C DA 1053/H… Show more | |
07/050 | 07/21/2025 1540 | 11/18/2025 1540 | OBST TOWER LGT (ASR 1006517) 390536.20N0943522.40W (1.8NM S MKC) 979.7FT (99.7FT AGL) U/S |
5/5223 | 07/12/2025 1800 | IAP KANSAS CITY DOWNTOWN/WHEELER FLD, KANSAS CITY, MO.
ILS OR LOC RWY 19, AMDT 24A...
RNAV (GPS) RWY 22, AMD… Show more | |
06/029 | 06/14/2025 1302 | 07/29/2025 1301 | OBST TOWER LGT (ASR 1209439) 390341.00N0944041.80W (5.4NM SW MKC) 1387.1FT (409.1FT AGL) U/S |
4/4228 | 03/29/2024 2000 | 03/19/2026 0900 | STAR CHARLES B WHEELER, KANSAS CITY, MO BRAYMER
EIGHT ARRIVAL..PROCEDURE AMEND SPINNER TRANSITION, MOCA 2700… Show more |
5/5581 | 02/21/2025 1921 | IAP CHARLES B WHEELER DOWNTOWN, KANSAS CITY, MO.
RNAV (GPS) Z RWY 19, AMDT 2...
LPV DA* 1029/HAT 275, VIS AL… Show more | |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 118.4 | Kansas City | |
ASOS | 120.75T (816) 329-2843 | Downtown | |
ATIS | 120.75 | Downtown | |
BRAYMER STAR | 120.95 | Kansas City | |
CD PRE TAXI CLNC | 121.9 | Downtown | |
Ground Control | 121.9 | Downtown | |
JHAWK STAR | 120.95 | Kansas City | |
Tower | 133.3 | Downtown | |
TYGER STAR | 120.95 | Kansas City | |
UNICOM | 122.95 | Downtown |
