FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 16 | 34 |
Elevation: | 248.6 ft | 220.8 ft |
Heading: | 164° magnetic 180° true | 344° magnetic 360° true |
Gradient: | 0.46% down | 0.46% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | basic, in Fair condition | basic, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | 503 ft | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 337 ft Right ft of center, 79 ft high, 1,123 ft from end, 11:1 clearance slope | Trees, 295 ft Right ft of center, 67 ft high, 1,300 ft from end, 16:1 clearance slope |
Comments: | n/a | Papi Rwy 34 Unusbl Byd 5.4 Nm; Does not Prvd Obstn Clnc Byd 5.4 Nm Fm Thr. FAA |
Designator: | 10 | 28 |
Elevation: | 233.4 ft | 227.6 ft |
Heading: | 097° magnetic 113° true | 277° magnetic 293° true |
Gradient: | 0.16% down | 0.16% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | basic, in Fair condition | basic, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Road, 200 ft Right ft of center, 15 ft high, 200 ft from end | Hill, 235 ft Right ft of center, 5 ft high, 240 ft from end, 8:1 clearance slope |
Comments: | 7 Ft Fence 435 Ft W of Thr. FAA Ctl Obs Exceeds 45 Deg Slp. FAA Road 200 Ft R 5-200 Ft Fm Thr. FAA | Papi Rwy 28 Unusbl Byd 3.0 Nm; Does not Prvd Obstn Clnc Byd 3.0 Nm Fm Thr. FAA |
Designator: | 16S | 34S |
Elevation: | 238.5 ft | 231 ft |
Heading: | 164° magnetic 180° true | 344° magnetic 360° true |
Gradient: | 0.48% down | 0.48% up |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Not provided. Assume LEFT traffic pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | n/a | n/a |
Comments: | n/a | n/a |
Designator: | H1 |
Elevation: | 222 ft |
Markings: | n/a |
Obstructions: | n/a |
Comments: | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
08/007 | 08/04/2023 1656 | TWY H CLSD | |
05/047 | 05/28/2025 2250 | 08/01/2025 2359 | RWY 10/28 REDL U/S |
05/031 | 05/17/2025 0022 | 07/31/2025 0200 | TWY ALL EDGE LGT U/S |
05/006 | 05/08/2023 0800 | TWY B BTN TWY A AND TWY J CLSD | |
06/011 | 06/06/2025 0010 | 08/31/2025 2359 | AIRSPACE SEE ZAN 06/050 NUMEROUS ACFT WI AN AREA |
11/005 | 11/03/2023 1712 | TWY N COMMISSIONED 2400FT X 50FT ASPH LGTD | |
05/045 | 05/28/2025 2249 | 08/01/2025 2359 | RWY 16/34 REDL U/S |
05/007 | 05/08/2023 0800 | TWY L BTN RWY 10/28 AND TWY J CLSD | |
Light Aircraft 1200 MSL
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 118.6 | Anchorage | |
ASOS | 134.75T (907) 746-6675 | ||
CTAF | 123.6 |
