FAA Information Effective: May 15, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 02 | 20 |
Elevation: | 55.3 ft | 14.3 ft |
Heading: | 024° magnetic 035° true | 204° magnetic 215° true |
Gradient: | 0.59% down | 0.59% up |
Traffic Pattern: | Right Pattern | Left Pattern |
Markings: | precision, in Good condition | precision, in Good condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | ILS/DME | n/a |
Obstructions: | Stack, 500 ft Left ft of center, 198 ft high, 9,704 ft from end, 48:1 clearance slope | Building, 250 ft Left ft of center, 5 ft high, 300 ft from end, 20:1 clearance slope |
Comments: | n/a | High Trees 600 Ft Northwest Cntrln Extdd Ry 20. FAA |
Designator: | 05 | 23 |
Elevation: | 22.1 ft | 17.6 ft |
Heading: | 054° magnetic 065° true | 234° magnetic 245° true |
Gradient: | 0.09% down | 0.09% up |
Traffic Pattern: | Left Pattern | Right Pattern |
Markings: | non-precision, in Good condition | non-precision, in Good condition |
Approach Lighting: |
| n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 31 ft high, 1,200 ft from end, 28:1 clearance slope | Pole, 35 ft high, 1,500 ft from end, 37:1 clearance slope |
Comments: | +6 Ft Extndd Gnd 200 Ft Fm Thld & 220 Ft Each Side Cntrln; +32 Ft Lgtd Windsock 0 Ft Fm Thld & 230 Ft Southeast of Cntrln. FAA Papi Unusbl Byd 4 Nm Fm Thr Due to Rapidly Rising Terrain. FAA | n/a |
Designator: | H1 |
Elevation: | 49 ft |
Markings: | n/a |
Obstructions: | n/a |
Comments: | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
4/2819 | 02/08/2024 1732 | IAP KAHULUI, KAHULUI, HI.
ILS Y OR LOC Y RWY 2, ORIG-A...
ILS Z OR LOC Z RWY 2, AMDT 26A...
RNAV (GPS) RWY 2… Show more | |
06/002 | 06/01/2025 1900 | 06/15/2025 1600 | TWY A BTN TWY D AND TWY C CL MARKING NOT STD |
5/3711 | 03/17/2025 1335 | SID KAHULUI, KAHULUI, HI.
STACEY TWO DEPARTURE...
DEPARTURE ROUTE DESCRIPTION - TAKEOFF RUNWAY 20: CLIMB HEA… Show more | |
05/028 | 05/30/2025 1302 | 06/14/2025 1302 | OBST WIND TURBINE LGT (ASN 2013-WTW-10147-OE) 205135N1562526W (2.5NM S OGG) 318FT (72FT AGL) U/S |
05/027 | 05/29/2025 2213 | 06/05/2025 2211 | OBST WIND TURBINE LGT (ASN 2012-WTW-3608-OE) 204810N1563222W (7.6NM SW OGG) 2157FT (328FT AGL) U/S |
02/042 | 02/24/2025 1600 | 07/22/2025 0400 | AIRSPACE UAS WI AN AREA DEFINED AS 2NM RADIUS OF 204833N1561348W (11.4NM W HNM) SFC-400FT AGL DLY 1600-0400 |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure IC | 120.2 | NORTH | Hcf Approach |
Approach/Departure IC | 119.5 | SOUTH | Hcf Approach |
ASOS | (808) 877-6282 | Maui | |
ATIS | 128.6 | Maui | |
CLASS C | 120.2 | NORTH | Maui |
CLASS C | 119.5 | SOUTH | Maui |
Clearance Delivery | 120.6 | Maui | |
CTAF | 118.7 | Maui | |
Emergency | 121.5 | Maui | |
Ground Control | 121.9 | Maui | |
Tower | 118.7 | Maui | |
UNICOM | 122.95 | Maui |
