FAA Information Effective: Jul 10, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 01 | 19 |
Elevation: | 78.7 ft | 89.3 ft |
Heading: | 006° magnetic 000° true | 186° magnetic 180° true |
Gradient: | 0.17% up | 0.17% down |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Right Pattern |
Markings: | non-precision, in Good condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 225 ft Left ft of center, 49 ft high, 2,385 ft from end, 44:1 clearance slope | Trees, Both-Sides, 75 ft high, 3,365 ft from end, 42:1 clearance slope |
Comments: | n/a | n/a |
Designator: | 05 | 23 |
Elevation: | 85.4 ft | 87.9 ft |
Heading: | 049° magnetic 043° true | 229° magnetic 223° true |
Gradient: | 0.05% up | 0.05% down |
Traffic Pattern: | Not provided. Assume LEFT traffic pattern | Right Pattern |
Markings: | non-precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Trees, 235 ft Right ft of center, 59 ft high, 2,230 ft from end, 34:1 clearance slope | Trees, 155 ft Right ft of center, 42 ft high, 1,470 ft from end, 30:1 clearance slope |
Comments: | n/a | n/a |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
06/386 | 06/28/2025 1208 | 08/12/2025 1208 | OBST TOWER LGT (ASR 1060692) 281246.00N0820049.00W (7.6NM E ZPH) 439.6FT (324.8FT AGL) U/S |
07/326 | 07/21/2025 2244 | 08/21/2025 2359 | OBST TOWER LGT (ASR 1207985) 281345.20N0821127.00W (1.9NM W ZPH) 254.9FT (169.9FT AGL) U/S |
04/096 | 04/10/2025 1409 | 12/31/2025 2359 | OBST TOWER LGT (ASR 1301281) 281435.00N0821348.00W
(3NM W ZPH) UNKNOWN (300FT AGL) U/S |
5/1282 | 07/21/2025 2000 | ODP ZEPHYRHILLS MUNI, ZEPHYRHILLS, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKEOF… | |
04/135 | 04/14/2025 1409 | RWY 19 RWY END ID LGT U/S | |
07/236 | 07/16/2025 0433 | 07/31/2025 0333 | OBST TOWER LGT (ASR 1288783) 282847.70N0820357.00W (16.0NM NNE ZPH) 432.1FT (345.1FT AGL) U/S |
5/1057 | 04/24/2025 1755 | IAP ZEPHYRHILLS MUNI, ZEPHYRHILLS, FL.
RNAV (GPS) RWY 19, AMDT 1A...
LNAV/VNAV DA 477/HAT 387 ALL CATS, VIS … | |
Runway: | Applies to: | Approach/Departure: | Text: |
---|---|---|---|
All | All Aircraft | Both | Noise Sensitive Area Northeast & West of Arpt; Mntn Pat Alts & Avoid Pwr Chg Ovr Residential Areas. |
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 119.9 | Tampa | |
AWOS-3PT | 118.975T (813) 780-0031 | ||
Clearance Delivery Phone | (813) 878-2528 | Tampa Approach | |
CTAF | 123.075 | ||
UNICOM | 123.075 |
