FAA Information Effective: Jun 12, 2025
All information is provided from the FAA unless otherwise noted.
Attended
Designator: | 12 | 30 |
Elevation: | 797.1 ft | 796.7 ft |
Heading: | 128° magnetic 122° true | 308° magnetic 302° true |
Gradient: | 0.01% down | 0.01% up |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | non-precision, in Fair condition | non-precision, in Fair condition |
Approach Lighting: |
|
|
Displaced Threshold: | 241 ft | 251 ft |
ILS/LOC: | n/a | n/a |
Obstructions: | Tree, 275 ft Right ft of center, 39 ft high, 592 ft from end, 10:1 clearance slope | Tree, 250 ft Left ft of center, 34 ft high, 200 ft from end, 1:1 clearance slope |
Comments: | Apch Ratio 20:1 At Dsplcd Thr. FAA | Papi Unusbl Byd 5 Degs Left of Cntrln. FAA |
Designator: | 09 | 27 |
Elevation: | 794.7 ft | 798.2 ft |
Heading: | 093° magnetic 087° true | 273° magnetic 267° true |
Gradient: | 0.15% up | 0.15% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | 191 ft | 374 ft |
ILS/LOC: | n/a | n/a |
Obstructions: | Tree, 11 ft Right ft of center, 10 ft high, 96 ft from end, 9:1 clearance slope | Tree, 248 ft Right ft of center, 77 ft high, 1,001 ft from end, 13:1 clearance slope |
Comments: | 3 Ft Yellow Cones. FAA Apch Ratio 15:1 At Dsplcd Thr. +40 Ft Tree, 630 Ft Dist, 75 Ft L. FAA | 3 Ft Yellow Cones. FAA Apch Ratio 19:1 At Dsplcd Thr. +91 Ft Tree, 1785 Dist, 0 Ft Base Leg. FAA |
Designator: | 18 | 36 |
Elevation: | 797 ft | 798.1 ft |
Heading: | 185° magnetic 179° true | 365° magnetic 359° true |
Gradient: | 0.06% up | 0.06% down |
Traffic Pattern: | Left Pattern | Left Pattern |
Markings: | n/a | n/a |
Approach Lighting: | n/a | n/a |
Displaced Threshold: | n/a | n/a |
ILS/LOC: | n/a | n/a |
Obstructions: | Tree, 171 ft Right ft of center, 64 ft high, 732 ft from end, 11:1 clearance slope | Tree, 161 ft Right ft of center, 38 ft high, 233 ft from end, 6:1 clearance slope |
Comments: | 3 Ft Yellow Cones. FAA | 3 Ft Yellow Cones. FAA |
Number: | Start Date: (UTC) | End Date: (UTC) | Condition: |
---|---|---|---|
04/013 | 04/01/2025 1627 | 07/01/2025 0400 | OBST TOWER LGT (ASR 1213715) 423255.60N0851531.70W (7.9NM SSE 9D9) 1246.1FT (254.9FT AGL) U/S |
5/0013 | 06/06/2025 1449 | IAP HASTINGS, HASTINGS, MI.
VOR RWY 12, ORIG-I...
JCUBS FIX MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITAB… Show more | |
05/469 | 05/28/2025 0901 | 06/30/2025 2359 | OBST TOWER LGT (ASR 1006577) 423254.00N0852241.00W (7.1NM SSW 9D9) 1322.5FT (307.7FT AGL) U/S |
Light Aircraft 1601 MSL
Type: | Frequency / Phone: | Sector / Comments: | Call Sign: |
---|---|---|---|
Approach/Departure | 128.4 | Great Lakes | |
Clearance Delivery Phone | (269) 459-3344 | Great Lakes Approach | |
Clearance Delivery Phone | (630) 906-8921 | When Approach Closed | Chicago ARTCC |
CTAF | 123.075 | ||
UNICOM | 123.075 |
