AOPA Airports: North AF Aux (KXNO)

FAA Information Effective: 5/2/2013

AOPA members save at 3,000+ GA airports.Book Now!

KXNOUsaf
Private Use

North AF Aux

North, SC
Phone: 843-963-3028
Nearby airports

Overview

Attendance:	Attended Opr Mon 1100z Thru Fri 1100z; Closed Sat Sun, And Federal Hol.Year-round,Mon-Fri/
Tower:	Air Traffic Control Tower, 19 hrs/day, weekdays only
Elevation:	321 ft (97.8 m) (Estimated)
Location:	of North
Beacon:	Present (white-green)
Approaches:	DME, VOR
Runways:	05/23, 06/24 Longest paved runway: 10003 ft
Fees:	No data

Plain | Embed this

METARs
TAFs

Satellite
Diagram
Sectional

Open in Google Maps

AIRPORT DIAGRAM

Click chart for current METARs and aeronautical charts

Expand Additional Remarks

Misc: Ry 05-23 and 6-24 Grooved. Twr Ltd to Advsy Svc Only. Vfr Only. Cnl Ifr Clnc with Columbia App Prior to Opr at North Af Aux

Rstd: Ry 05/23 Clsd 1300-1500z++ Monthly 3rd Thu. Ry 06/24 Clsd 1601-2100z++ Monthly 3rd Thu

Rstd: Poc is Charleston Afb, 437 Oss/Oso, Dsn 673-5554, C843-963-5554. All Aircrews Will CTC North Dz on 118.15 235.775 Prior to 5nm to Dz. This Airspace is Subj to be Rstd by Notam. Rwy 06-24, No 180ø Star Turns on Asphalt, Conduct All Turns on Concrete Ends

Caution: Ry 6-24 Large Ditch 350 Ft Fr Ry Cntrline at Midfield on Nw Side Ry. Ints Gnd Trng on Reservation. Ry 5-23 Used As Ldg Zone 3500 Ft X 90 Ft

Caution: Ints Hvy Mil Jet and Misc Acft Executing Numerous Cargo and Pers Drops, Hi-Speed Lo-Level Formation Flt, and Airland Opr. Ry 6-24 Nw Tree Line 750' Fr Ry Cntrline

See Flip Ap/1 Supplementary Arpt Rmk

Caution: Mil Nvd Ops May be Conducted in Vcnty of Afld Anytime Btn Ss and Sr

Ils/Radar: Mmls No Notam Mp Thu 1300-1500z++

Caution: Ry 05/23 No Distance Marker Panels

Misc: Afld Surface Obs are Derived Fm Non-Augmented Asos. Lcl Pmsv Unavbl; Contact Charleston Metro-233.95

Rstd: Rcr Not Avbl

Rstd: Ry 6 & 24 Takeoff Distance Available 9000 Ft, Landing Distance Available 8000 Ft

Rstd: Txy Delta Clsd During Box-In-One Ops to Ry 23

Ns Abtmt: Ovft of North, Sc Proh

Rstd: Opr Rstd Dur Bird Watch Cond Moderate(Tkof or Ldg Perms Only When Dep/Arr Rte Avoid Ident Bird Act, No Lcl Ifr/Vfr Tfc Pat Act) and Severe (Tkof and Ldg Proh Wo Og/Cc Apvl), CTC Twr for Current Bird Watch Cond. Min 2 Wk Prior Coord Rqr for All Users

NOTAMs | TFR's

Runway 05/23

Dimensions:	3493 x 90ft. / 1064.7 x 27.4m	Weight Bearing Cap:
Surface:	asphalt, no surface treatment, condition not reported	Runway Edge Lights:

#	Elev/Hdg	Tr. Pat.	Approach Lights
05	292.8ft. MSL 0.8% up	No Data	No Data

23	320.7ft. MSL 0.8% down	No Data	No Data

Runway 06/24

Dimensions:	10003 x 150ft. / 3048.9 x 45.7m	Weight Bearing Cap:
Surface:	asphalt, no surface treatment, condition not reported	Runway Edge Lights:	high

#	Elev/Hdg	Tr. Pat.	Approach Lights	TD Point	Comments/Noise
06	266.0ft. MSL 0.5% up	No Data	No Data	1000' Disp Threshold	& 24 9000 Ft Avbl for Lndg

24	316.0ft. MSL 0.5% down	No Data	No Data	1004' Disp Threshold

Business/Service Information

List Your Business in AOPA Airports

Expand Member Comments

AOPA member comments are are offered unedited and do not necessarily reflect the views of AOPA.

Only current AOPA members and business managers can post comments. Make sure you are logged in.

Are you sure you want to delete this comment?

Cancel Delete

Member-submitted Photos

View all
Upload your photos of North AF Aux

Operations & More Information

Lat/Long:	N33 36.5695' / W81 4.8706'33.6094909-81.0811773
Charts:	NACO: Charlotte Sectional
Mag Var:	05W (1985)
ARTCC:	Jacksonville (ZJX)
FSS:	Anderson (AND) 1-800-WXBRIEF
NOTAM Facility:	CHS
Approach/Departure Control Facility	CAE
Pattern Altitude:	Rectangular 1300 Ft, Overhead 1800 Ft
Wind Indicator:	Not Present
Seg. Circle:	No
Lighting:	Rotg Bcn Off Dur Lgt Out Trng Activate HIRL Rwy 6-24 131.1

Air Safety Institute Resources

Accident Reports

Expand Communications Card

Type	Location/Call	Freq./Phone
Approach/Departure	Columbia	124.15
WX	North	118.525T
Clearance-Delivery	North	120.475
CTAF	North	118.15
GND ADZY	Columbia	120.475
Tower Ground Control	North	118.15

Expand Navaids

ID	Type	Freq	Radial	Distance
EDS	VOR/DME	111.4	316	15 nm
CAE	VORTAC	114.7	187	15 nm
MMT	VORTAC	113.2	222	23 nm
AIK	NDB	347.0	101	30 nm
VAN	VORTAC	110.4	290	33 nm
ALD	VOR	116.7	017	37 nm
SSC	TACAN	.0	240	38 nm
FDW	NDB	414.0	185	42 nm
SMS	NDB	252.0	245	43 nm
MNI	NDB	381.0	278	44 nm
RBW	NDB	221.0	337	47 nm
EMR	NDB	385.0	083	47 nm

Contact Addresses

Owner:	Airport Manager:
USAF	Larry Gill
Shaw Afb	North Af Aux
Sumter, SC 29152	North, SC 29112

	Airport Manager Admin
Af Base Ops Poc

APD	AIRPORT DIAGRAM	92.7 KB
IAP	VOR/DME-A	180.4 KB
MIN	TAKEOFF MINIMUMS	140.1 KB
