Beechcraft P35 Bonanza

Overview

• The Beechcraft P35 Bonanza is an American classic, earning an outstanding reputation for its speed, reliability, and quality craftsmanship. The Bonanza is also well known for its unique v-tail, making it stand out from the rest.

  Beechcraft P35 Bonanza

Specifications

• Powerplant

  Continental IO-550-B82B, 300 hp; boosted to 315 hp with D'Shannon tuned intake and exhausted

• Propellers

  Hartzell three-blade scimitar

• Length

  25 ft 1.24 in

• Height

  7 ft 7 in

• Wingspan

  35 ft 5.5 in

• Wing Area

  180.94 sq ft

• Wing loading

  17.82 lb/sq ft

• Power loading

  10.75 lb/hp

• Cabin Width

• Empty Weight

  1,270 lb

• Maximum gross weight

  3,125 lb

• Useful load

• Payload with full fuel

• Fuel capacity

  80 gal (74 gal usable)

• Baggage capacity

  270 lb

Performance

• Takeoff distance ground roll

  2,100 ft

• Takeoff distance over 50-ft obstacle

  2,800 ft at 5,650 msl/59 degrees F

• Rate of climb sea level

  1,150 fpm

• Service ceiling

  18,000 ft

• Landing distance over 50-ft obstacle

  1,800 ft at 5,650 ft msl

• Landing distance ground roll

  1,100 ft

• Cruise speed/endurance w/45-min rsv, std fuel (fuel consumption, ea engine) @ 75% power, best economy

  176 kt at 19 in, 2,600 rpm ROP at 10,000 ft msl (16.5 gph)

• Range

  535 nm

Limiting and Recommended Airspeeds

• V_X

  74 KIAS

• V_Y

  90 KIAS

• V_NE

• V_S1

  60 KIAS

• V_SO

  50 KIAS

All specifications are based on manufacturer's calculations. All performance figures are based on standard day, standard atmosphere, sea level, gross weight conditions unless otherwise noted.
