    Photography by David Tulis.
  • SLIDE SHOW COMPONENT
    A touchscreen Garmin G3X primary flight display/multifunction display provides a wealth of flight, navigation, and engine information to the pilot. The Wipaire landing gear advisory system on the right side of the G3X shows four blue lights meaning the wheels are up for water takeoffs and landings. Four green lights would indicate the wheel are down for landing on a hard surface.

Overview

  • The CubCrafters NXCub is an adventure pilot’s dream, featuring remarkable STOL performance, generous useful load, class defining speed and cross-country range. Additionally, both the pilot and passengers are provided with high-quality comfort and convenience.

    CubCrafters NXCub

Specifications

  • Powerplant

    CC393i (215 hp)

  • Propellers

    Trailblazer constant speed

  • Length

    23 ft 10 in

  • Height

    10 ft 1 in

  • Wingspan

    34 ft 4 in

  • Wing Area

    174.8 sq ft

  • Wing loading

  • Power loading

  • Cabin Width

    30 in (at pilot position)

  • Empty Weight

    1,696 lb

  • Maximum gross weight

    2,300 lb

  • Useful load

    604 lb

  • Payload with full fuel

  • Fuel capacity

    49 gal

  • Baggage capacity

    26 cu ft

Performance

  • Takeoff distance ground roll

    120 ft

  • Takeoff distance over 50-ft obstacle

  • Rate of climb sea level

    645 fpm

  • Service ceiling

  • Landing distance over 50-ft obstacle

  • Landing distance ground roll

    400 ft

  • Cruise speed/endurance w/45-min rsv, std fuel (fuel consumption, ea engine) @ 75% power, best economy

    110 KTAS @ 75% power / 4 hours with VFR reserves

  • Range

    400 nm

Limiting and Recommended Airspeeds

  • VX

    51 KIAS

  • VY

    64 KIAS

  • VNE

    145 KIAS

  • VS1

  • VSO

    40 KIAS

For more information, contact CubCrafters at or via https://cubcrafters.com/xcub

All specifications are based on manufacturer's calculations. All performance figures are based on standard day, standard atmosphere, sea level, gross weight conditions unless otherwise noted.
