Pneumatic Systems

Safety Spotlight: Aircraft Systems

aircraft flying above the clourds

Pneumatic systems, commonly known as vacuum or pressure systems, power the heading and attitude indicators in most general aviation (GA) aircraft, and in many aircraft, also power the autopilot and de-ice systems. For pilots who regularly fly at night or in instrument meteorological conditions (IMC) these systems are critical to the safety of flight.



While accidents due to pneumatic system failures are rare, they are almost always fatal.

Basic Operation

At the heart of pneumatic systems in GA aircraft is a pressure or vacuum-creating engine driven air pump.

There are two basic types of air pumps: wet and dry. Wet air pumps use engine oil to lubricate the inside of the pump. The more common dry air pumps have graphite vanes inside the casing which self-lubricate as they rotate. In both cases, the air pump draws air into the system through a filter. The fast-moving stream of air passes over the vanes within the heading and attitude indicator gyros, causing the gyroscopes to rotate at about 10,000 rpm.

Early Recognition of System Failure

Early recognition of a pneumatic system failure is important during any operation, but when flying IMC or night VFR it could be the difference between life and death.

First you must understand which flight instruments are pneumatically powered. In most aircraft, these are the heading and attitude indicators, although in some newer aircraft these flight instruments are electrically powered. Make sure to check the aircraft’s pilot operating handbook (POH) for specifics.

While pneumatic system failures alone do not cause accidents, spatial disorientation does, and tragically those accidents are almost always fatal.

If the autopilot is also powered by the pneumatic system, the consequences of a system failure are magnified; just when the autopilot is needed the most, it’s no longer reliable.

Real Pilot Story: Vacuum Failure in IMC

This Real Pilot Story shows how important it is to be proficient and prepared in the event of an instrument failure during flight in instrument meteorological conditions. As Dr. Donna Wilt can attest, practice partial panel in realistic situations, be resourceful, and know when to declare an emergency and use ATC’s help.engine

Signs of Failure

The first warning signs of pneumatic system failure can be subtle. Vacuum or pressure powered flight instruments will slowly begin to give conflicting and inaccurate information. Proficiency in instrument scanning is vital because a low reading from the suction or pressure gauge will often signal a failure before the gyros start giving inaccurate indications.

Pilots should consider installing easily visible annunciator warning lights, inoperative flags on the gyros, or flow indicators for early warning of a pneumatic system failure.

Early recognition of a pneumatic system failure can significantly decrease the chances of spatial disorientation. While pneumatic system failures alone do not cause accidents, spatial disorientation does, and tragically those accidents are almost always fatal.

To help avoid spatial disorientation:

  • Install a backup power supply to the pneumatic system
  • Keep the suction gauge in your instrument scan
  • Develop and maintain proficiency at partial panel flying
  • Cover up inoperative instruments during a failure
  • Make timed turns instead of relying on the heading indicator
  • Notify ATC of the situation and declare an emergency
  • If in IMC, consider flying toward the closest VMC
  • Check the weather at the nearest airport with a precision instrument approach
  • Ask ATC for a “no gyro approach”

Pneumatic system failures can occur at any time, regardless of the age of the system. Causes include:

  • Contamination by solid particles from within the pneumatic systems that can damage the pump and plug valve openings
  • Liquid contamination from oil, water, or engine cleaning solvents
  • A loose fitting or damaged hose allowing contaminants into the system past the filter
  • Worn out, misused, or incorrectly routed hoses
  • Abrupt engine deceleration (which can be caused by the propeller hitting water or tall grass)
  • Sudden engine stoppage, such as that caused by a prop strike against a solid object

Whether you’re an aircraft owner, renter, or operator, defense against pneumatic system failure begins with a review of the maintenance logs and a talk with the mechanic who most recently worked on the aircraft. Study and adhere to the aircraft and component part manufacturer’s recommendations regarding inspection and replacement intervals of pneumatic system component parts.

Accident Case Study: Single Point Failure

A vacuum pump failure on a sunny day is no big deal, but in IMC—and especially without backup instrumentation—it’s a serious emergency. To see how a Bonanza pilot coped with that situation, and learn how you can do better, watch Accident Case Study: Single Point Failure.
